BITMAIN 1800W official power APW3++ PSU 1600W Bitmain D3 S9 S7 L3 B3 X3 T9

BITMAIN 1800W official power APW3++ PSU 1600W Bitmain D3 S9 S7 L3 B3 X3 T9

antminer
item image

Price: 162.70 USD

Crypto Miner:

BITMAIN 1800W official power APW3++ PSU 1600W Bitmain D3 S9 S7 L3 B3 X3 T9



eBay

Description:

*The APW3++ can deliver a maximum power of only 1200W if it is connected to a 110V mains power supply. To obtain the rated power of 1600W,

the APW3++ must be connected to a 220-240V mains power supply. Please check the mains power supply that is the standard in your region before ordering.

* This batch of PSU comes with only 10 PCIe connectors so cannot be used with more than one Antminer L3+ miner.

Specifications:

Weight:

Gross Weight: 2.1kg

Package size:

32.7*16.8*12.6cm

Output

*DC Voltage:12.15V

*Rated Current(220V input): 133A

*Rated Current(110V input): 100A

*Rated Power(220V input): 1600W

*Rated Power(110V input): 1200W

*Ripple & Noise: <1%

*Voltage Regulation: <2%

*Source Regulation: <1%

*Load Regulation: <1%

*Setup, Rise Time: <2s

*Power off Protection Trip Time: >9mS

*Interface Type: 5 pairs of 6 pin PCI-E connectors (i.e. 10 connectors)

*Noise Level: <43db

Input:

*Voltage Range: 100-240V AC

*Starting Voltage: 95-105V AC

*Frequency Range: 47-63Hz

*Power Factor: >0.95 (full load)

*Leakage Current: <1.5mA (220v 50Hz)

Protection

1.Low-voltage Input:80-89V AC

2.Output Short Circuit:Yes

3.Output Overcurrent:134-185A max.

4.Overheat Protection:Yes

Environment Conditions

1.Operating Temperature: -20°C – 50°C

2.Operating Humidity: 20% – 90% relative humidity (non-condensing)

Structure

Dimensions: 220mm*108mm*62mm

Cooling

Fan:Forced-air cooling

Package includes:

1 x APW3 power supply for Antminer D3 S9 S7 L3 X3 B3 Z9 T9 V9

Note:

*The power cord is not included, please find one with at least 10A from your local market or in my store

*This item is not supplied for Antminer G1 R1

*The best temperature of this item to work is 15-35 ℃.
